Product Descriptions:

• Double capacity: The TLW provides twice the capacity of a conventional hood-type dishwasher, thanks to an additional wash chamber - but with the same space requirement.
• Maximum flexibility: Simultaneous washing of different wash ware, such as porcelain dishes, cutlery or  cooking utensils, in two separate wash chambers.
• Space saving wash organisation: For heavily soiled wash ware, the TLW has a special utensil wash programme. Due to the extended washing time, the pre-soaking effect is already integrated into the washing process, so that the wash ware no longer need to pre-soaked. This saves valuable space in the kitchen organisation.
• VISIOTRONIC-TOUCH control: colour touchscreen (displays text and graphic) in conjunction with single button control and remaining cycle time indication.
• WASHSMART App: controlling your warewash operation with smart technology: status and messages, usage and operating costs, hygiene, service and consumables order.
• SENSO-ACTIVE resource management: constantly measures the quality of the wash water and keeps the amount of rinsing needed in each rinse cycle to the minimum in order to guarantee a fully hygienic wash result.
• Exhaust energy storage: the fully enclosed 4-sided hood keeps steam and energy inside the system: energy saving up to 3 kW, less humidity in the kitchen area and better hygienic conditions.
• CLIP-IN wash and rinse arms: wash and rinse arms can be removed with one hand and without any tools
• Interlocked strainer: prevents operation without tank strainer.
• EASY-CLEAN concept: blue markings in the machine help the operator to identify the components which require cleaning.
• Thermolabel 71°C: default temperatures setting acc. European DIN can be switched by operator to a higher thermolable setting.


MODEL : TLW

Cycle Times* 60 / 90 / 180 sec. & special cycles

Water Consumption Upper Level: 2.0 l/rack ; Lower Level: 2.5 l/rack

Tank Capacity 30 L

Tank Heating 3 kW

Power Supply 415 / 50 / 3N

Booster Loading - Standard 9.1 kW

Total Loading - Standard 13.6 kW l 3 x 25A

Total Loading - Alternative 10.4 kW l 3 x 20A

Wash Pump 1.2 kW

Rack Size 500 x 500 mm

Loading Height Upper Level: 440mm ; Lower Level: 235mm

Noise Level 70 dB (A)

Weight (gross / net) 160 / 140 kg
