Product Features:

• Powerful Twin-Level Dishwasher engineered to efficiently clean a large number of items, featuring independent washing arms for each deck to ensure optimal performance and thorough cleaning on both levels.
• Constructed entirely from 100% AISI Stainless Steel with no plastic components. This machine delivers exceptional strength, the highest level of durability, and long-lasting performance, making it ideal for demanding environments.
• Full AISI304 stainless-steel components including armoured stainless steel elements, stainless steel boiler, filters, hinges, upstands, wash arms, rinse arms, plugs and jets.
• Double-walled, fully insulated door ensures improved insulation and energy efficiency
• Magnetic microswitch automatically cuts off the appliance's operation when the hood is opened, ensuring safety during use.
• Independent twin stainless steel upper and lower washing and rinsing arms on each level which are easily removable for effortless cleaning and maintenance.
• The tank is constructed with rounded corners, ensuring easy cleaning and maintaining the highest hygiene standards.
• The full-width stainless steel wash tank filters are easy to remove, providing efficient drainage, best-in-class filtration, and complete access to the tank for thorough cleaning and maintaining hygiene.
• High-capacity gravity waste outlet features a front-accessible stainless steel lever tap control release for easy water drainage.
• The boiler and tank are heated through thermostatically protected armored stainless steel heating elements, ensuring efficient heat exchange and enhanced safety.
• Built-in insulated atmospheric rinse tank is constructed from AISI 304 stainless steel, providing best in class insulation and durability for optimal performance.
• Water levels are designed to sit below the tank filter line for improved health and safety. This makes them the ideal model for large restaurant chains and contract customers.
• Touch control panel features 5 preset wash cycle times (3-5-7-9-11 minutes) offering easy operation and the flexibility to select the ideal cycle for different cleaning needs.
• The displays show the current temperatures of both the boiler and tank, providing real-time visual monitoring.
• The display features a countdown of the washing cycle in minutes and seconds, providing real-time tracking of the remaining time for each cycle.
• Fully programable digital interface with adjustable wash and rinse timings and special settings. It allows Technical onboard diagnostics and error reporting for ease of maintenance
• Outstanding wash results are guaranteed with a high-powered wash pump, ensuring thorough cleaning at 60ºC, followed by a hygienic rinse at 85ºC for optimal sanitation.
• Built-in secondary powerful rinse booster pump, constructed from stainless steel, guarantees optimal rinse pressure for superior cleaning performance.
• Built-in detergent pump with easy dosage adjustments ensure precise and efficient use of cleaning agents.
• The self-cleaning cycle (CLN) automatically cleans the machine to the highest hygiene standards at the press of a button, ensuring safe handling and minimal effort.
• The washing chamber features two 31 cm clearance, allowing for the accommodation of larger items and providing flexibility for various washing needs.
• Accommodates 1 x 130x69 cm and 1 x 130x65xm baskets


Product Specifications:

Model

UT 9130.13AD

Voltage

400 Volts

Watts

16800 watts

Amperage

24.3 Amps PP

Plug Supplied

No

Tank capacity

88 Litres

Washing pump

2 x 2400 watts

Rinse Pump

2 x 300 watts

Drain Pump

40 watts

Tank Heating element

9000 watts

Boiler Heating (supplied)

2 x 6000 watts

Boiler capacity

34 Litres

Water consumption

25 Litres per cycle

Rinse Temp

82 °C

Wash temp

60 °C

Washing height

310mm per rack

Basket Size

Lower 1300 x 690mm | Upper 1300 x 650mm Baskets

Cycle times

3-5-7-9-11 minutes

Noise level

< 70 dbA.

Width (mm)

1440

Depth (mm)

810

Height (mm)

1900

Warranty

2 years

Inclusions

1 x Lower Flat Basket 130 x 69cm
1 x Upper Flat Basket 130 x 65 cm
1 x Insert for 10 Trays with 30mm spacing
1 x Insert for Squirtbags
1 x Cutlery Container
