Product Features:

• Built-in integrated heat recovery system captures heat generated during operation to preheat the rinsing water, and further storing it for use in a tank for the next cycle allowing a direct reduction in consumption by 44%.
• Integrated steam condensation system with a 30-second steam extraction process. No saturated steam is used, and no external aspiration system is required.
• Constructed entirely from 100% AISI Stainless Steel with no plastic components. This machine delivers exceptional strength, the highest level of durability, and long-lasting performance, making it ideal for demanding environments.
• Full AISI304 stainless-steel components including armoured stainless steel elements, stainless steel boiler, filters, hinges, upstands, wash arms, rinse arms, plugs and jets.
• Double-wall fully insulated stainless steel construction providing enhanced thermal efficiency, sound insulation and best in class energy consumption.
• Double-walled, fully insulated hood ensures improved insulation and energy efficiency
• Magnetic microswitch automatically cuts off the appliance's operation when the hood is opened, ensuring safety during use.
• Independent stainless steel upper and lower washing and rinsing arms, which are easily removable for effortless cleaning and maintenance.
• Double Walled washing tank is constructed with rounded corners, ensuring easy cleaning, highest hygiene standards ande best in class thermal efficiency.
• The full-width stainless steel wash tank filters are easy to remove, providing efficient drainage, best-in-class filtration, and complete access to the tank for thorough cleaning and maintaining hygiene.
• The Drain Pump features front panel filter access to prevent unnecessary warranty issues and breakdowns. This allows easy removal of foreign material from the pump, providing an extra safeguard alongside the machine's filtration systems.
• The boiler and tank are heated through thermostatically protected armored stainless steel heating elements, ensuring efficient heat exchange.
• The water heating in the tank is indirect, so there is no heating element inside the tank allowing for easy cleaning and Hygiene.
• Built-in insulated atmospheric rinse tank is constructed from AISI 304 stainless steel, providing best in class insulation and durability for optimal performance.
• Water levels are designed to sit below the tank filter line for improved health and safety. This makes them the ideal model for large restaurant chains and contract customers.
• Touch control panel features 5 preset wash cycle times (90-120-150-180-210 seconds) offering easy operation and the flexibility to select the ideal cycle for different cleaning needs.
• The displays show the current temperatures of both the boiler and tank, providing real-time visual monitoring.
• The display features a countdown of the washing cycle in minutes and seconds, providing real-time tracking of the remaining time for each cycle.
• Fully programable digital interface allows complete adjustment of wash and rinse timings aswell as special programs for reverse osmosis and other requirements. It also offers technical onboard diagnostics and error reporting to facilitate easy maintenance
• Outstanding wash results are guaranteed with a high-powered wash pump, ensuring thorough cleaning at 60ºC, followed by a hygienic rinse at 85ºC for optimal sanitation.
• Built-in drain pump with a filter ensures efficient drainage while preventing debris from clogging, maintaining optimal performance
• Built-in secondary powerful rinse booster pump, constructed from stainless steel, guarantees optimal rinse pressure for superior cleaning performance.
• Built-in detergent and rinse aid pumps with easy dosage adjustments ensure precise and efficient use of cleaning agents.
• Built-in timed manual cold rinse quickly cools heated glasses and dishes. This function is available when the machine is connected to Cold Water. If the machine is connected to Hot Water, it will act as a secondary Hot Rinse.
• The self-cleaning cycle (CLN) automatically cleans the machine to the highest hygiene standards at the press of a button, ensuring safe handling and minimal effort.


Product Specifications:

Model

HT 504.23RVT

Voltage

400 Volts

Watts

9900 watts

Amperage

14.3 Amps PP

Plug Supplied

No

Tank capacity

25 Litres

Washing pump

900 watts

Rinse Pump

300 watts

Drain Pump

40 watts

Tank Heating element

3000 watts

Boiler Heating (supplied)

9000 watts

Boiler Heating (configurable)

6000 watts

Boiler capacity

13 Litres

Washing Power

400 to 1200 pc/hr

Water consumption

3.5 Litres per cycle

Clean Water discharge

2.5 Litres per cycle

Rinse Temp

82 °C

Wash temp

60 °C

Washing height

Glasses 410mm | Plates Ø44

Basket Size

500 x 500mm

Cycle times

60-90-120-150-180 seconds

Noise level

< 70 dbA.

Width (mm)

635

Depth (mm)

735

Height (mm)

1675

Warranty

2 years

Inclusions

1 x Square Basket 50x50 cm (18 Plates)
1 x Square Basket 50x50 cm (18 flat Plates)
1 x Flat square Basket 50x50 cm
2 x Cutlery Holders
